binoculars λ 0832/0842/1042
Low dispersion (ED) glass lens, to achieve color-variation compensation, and make observation more clear
BAK4 prism + Highly reflective dielectric film + phase film optical technique to improve Color Accuracy and image uniformity
IPX7 Nitrogen filled waterproof （water depth 1m, available to soak 30 minutes) antifogging
Magnesium aluminum alloy body, antioxidant，fall resistance strong , high and low temperature resistance, make time expend
UHD optical system to capture every detail clearly
BAK4 prism + Highly reflective dielectric film + phase film optical technique to improve Color Accuracy and image uniformity
IPX7 Nitrogen filled waterproof （water depth 1m, available to soak 30 minutes) antifogging
Magnesium aluminum alloy body, antioxidant，fall resistance strong , high and low temperature resistance, make time expend
UHD optical system to capture every detail clearly
Inqury Now
QR code
ParameterWarranty
| POWER | 8x | 8x | 10x | |
| OBJ.LENS DIA. | mm | φ32, ED glass | φ42, ED glass | φ42, ED glass |
| TYPE OF PRISM | Type / Material | BaK4 | BaK4 | BaK4 |
| PRISM COATING | Yes / No | Phase&Dielectric | Phase&Dielectric | Phase&Dielectric |
| NUMBER OF LENS | Pieces & Groups | 8pieces6groups | 8pieces6groups | 8pieces6groups |
| LENS COATING | CL/FC/BMC/FBMC | FBMC | FBMC | FBMC |
| FOCUS SYSTEM | Cent. / Ind. / Fix | Center | Center | Center |
| FOCUSING LENS | Eye. / Obj. / Int. | int. | int. | int. |
| EXIT PUPIL DIAMETER | mm | φ4 | φ5.2 | φ4.27 |
| EXIT PUPIL DIST. | mm | 15.6 | 17.2 | 15.2 |
| FIELD OF VIEW | ANGLE | 7.8° | 8.1° | 6.5° |
| Ft/1,000Yds | 410ft | 426ft | 340ft | |
| M/1,000M | 137m | 142m | 113m | |
| MIN. FOCAL LENGTH | M / Ft. | 2m | 2.5m | 2.5m |
| RESOLUTION | 5.2" | 4" | 4" | |
| DIOPTER SYSTEM | Right eyepiece | Right diopter ring | Right diopter ring | |
| DIOPTER COMP. | + - Optic.Degree | ±3 | ±3 | ±3 |
| INTERPUPILLARY DIST. | mm | 55~73 | 56~74 | 56~74 |
| LTR | % | 88-90% | 88-90% | 88-90% |
| WEATHER PROOF | Yes / No | yes | yes | yes |
| WATER PROOF | Depth / Time | IPX7 | IPX7 | IPX7 |
| NITROGEN FILLED | Yes / No | yes | yes | yes |
| EYECUPS SYSTEM | Rubber/Pop-up/Twist-up | Twist-up | Twist-up | Twist-up |
All optical products bought from Kunming ShuntuOptical are quality guaranteed with lifetime warranty.
Our optical products are made with highquality materials, flawless production and strict QC test , complies with theFederal Trade Commission. Please contact info@shuntuoptics.com for any questions.
